1771-KX1 1771KX1 Allen Bradley AB PLC 5 Communication Interface Module
⇒ Click here for good price 1771-KX1
| Brand/Manufacturer | AB/USA |
| Part Number | 1771-KX1 |
| Alternate Part Number | 1771-KX1 |
| Description | Communication Interface Module |
| Dimennsions | 12.6cm x 8.5cm x 4.6cm |
| Weight | 0.39kg |
Product Details
The 1771-KX1 Interface Module for the PROVOX Instrumentation System by AB is an electronic device which provides an interface and a unidirectional gateway between a data highway and the Fischer Control’s PROVOX System. It can communicate with 1-8 programmable controller systems connected to the data highway. The 1771-KX1 is a stand-alone interface module which provides communication channels between the Fischer Control’s Programmable Controller Interface Unit (PCIU) by using the RS-232-C port connected through the 100ft (max) 1770-CX1 RS-232-C adapter cable, and the data highway using the 15-pin data highway cable.
The 1771-KX1 communicates with the PCIU at selectable communication rates of 110-19,200 bits per second, and with the data highway at a recommended rate of 56,000 bits per second. The maximum length it can maintain for standard communication with the PCIU is 50ft (15m), the maximum length for the data highway is 100ft (30m), and the maximum length through the data highway trunk line is 10,000ft (3048m). The 1771-KX1 has a power requirement of 1.2A at 5V DC and it uses a recommended user-supplied power supply source (1771-P2) with ratings of 3-5V DC (High) and -0.2-0.6V DC (Low). The 1771-KX1 has an ambient functional temperature range of 0-60° C (32-140°F) at a humidity range of 5-95% without condensation, and an ambient non-operating temperature range of -40-85° C (-40-185°F).
